"Intelligent" SSR met ingebouwde transformator voor het detecteren van een storing als gevolg van een doorgebrand verwarmingselement of kortsluiting
De G3PF detecteert snel een doorgebrand verwarmingselement en een storing tengevolge van kortsluiting. U krijgt informatie over het probleem dat zich heeft voorgedaan, ideaal voor toepassingen waarbij stilstand tot een minimum beperkt moet blijven.
- Dankzij ingebouwde transfomator (CT) minder bedrading
- Detecteert het doorbranden van een verwarmingselement
- Detecteert het doorbranden van 3-fasige verwarmingen
- Detecteert storingen tengevolge van kortsluitingen
- Foutdetectieniveau kan eenvoudig met een schakelaar worden ingesteld
- Nuldoorgangfunctie
- Bedrijfsindicator.
| Product | Application | Number of phases | Mounting method | Terminal | Complete with socket | With LED indicator | Rated operational voltage, AC | Operating voltage range, AC | Rated operation current Ie at AC-1 | Height | Width | Depth | Supply voltage DC | Control current max. | Must operate voltage max. | Must release voltage min. | Maximum operating temperature | Minimum operating temperature | Isolation | Switching at zero-crossing | Functions | Description |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| ON/OFF control | 1 | DIN rail/screw | Push-in | No | Yes | 100-240 V | 75-264 V | 25 A | 100 mm | 45 mm | 117 mm | 9.6-26.4 V | 10 mA | 9.6 V | 1 V | 60 °C | -20 °C | Phototriac | Yes | HB/HS alarm for 1-phase heaters | Solid-state relay 25A, 100-240VAC, with built in current transformer, jack-in cage clamp terminals, 2 alarms | |
| ON/OFF control | 1 | DIN rail/screw | Screw | No | Yes | 100-240 V | 75-264 V | 25 A | 100 mm | 45 mm | 110 mm | 9.6-26.4 V | 10 mA | 9.6 V | 1 V | 60 °C | -20 °C | Phototriac | Yes | HB/HS alarm for 1-phase heaters | Solid-state relay 25 A, 100 to 240 VAC, with built in current transformer, M3 terminals, 1 alarm | |
| ON/OFF control | 1 | DIN rail/screw | Push-in | No | Yes | 100-240 V | 75-264 V | 35 A | 100 mm | 55 mm | 137 mm | 9.6-26.4 V | 10 mA | 9.6 V | 1 V | 60 °C | -20 °C | Phototriac | Yes | HB/HS alarm for 1-phase heaters | Solid-state relay 35 A, 100 to 240 VAC, with built in current transformer, jack-in cage clamp terminals, 2 alarms | |
| ON/OFF control | 1 | DIN rail/screw | Screw | No | Yes | 100-240 V | 75-264 V | 35 A | 100 mm | 55 mm | 130 mm | 9.6-26.4 V | 10 mA | 9.6 V | 1 V | 60 °C | -20 °C | Phototriac | Yes | HB/HS alarm for 1-phase heaters | Solid-state relay 35 A, 100 to 240 VAC, with built in current transformer, M3 terminals, 1 alarm | |
| ON/OFF control | 1 | DIN rail/screw | Push-in | No | Yes | 200-480 V | 180-528 V | 25 A | 100 mm | 45 mm | 117 mm | 9.6-26.4 V | 10 mA | 9.6 V | 1 V | 60 °C | -20 °C | Phototriac | Yes | HB/HS alarm for 3-phase heaters | Solid-state relay 25A, 200-480VAC, with built in current transformer, jack-in cage clamp terminals, 2 alarms | |
| ON/OFF control | 1 | DIN rail/screw | Screw | No | Yes | 200-480 V | 180-528 V | 25 A | 100 mm | 45 mm | 110 mm | 9.6-26.4 V | 10 mA | 9.6 V | 1 V | 60 °C | -20 °C | Phototriac | Yes | HB/HS alarm for 3-phase heaters | Solid-state relay 25A, 200 to 480 VAC, with built in current transformer, M3 terminals, 1 alarm | |
| ON/OFF control | 1 | DIN rail/screw | Screw | No | Yes | 200-480 V | 180-528 V | 25 A | 9.6-26.4 V | 10 mA | 9.6 V | 1 V | 60 °C | -20 °C | Phototriac | Yes | HB/HS alarm for 3-phase heaters | Solid-state relay 25A, 200-480VAC, with built in current transformer, jack-in screw terminals, 2 alarms | ||||
| ON/OFF control | 1 | DIN rail/screw | Push-in | No | Yes | 200-480 V | 180-528 V | 35 A | 100 mm | 55 mm | 137 mm | 9.6-26.4 V | 10 mA | 9.6 V | 1 V | 60 °C | -20 °C | Phototriac | Yes | HB/HS alarm for 3-phase heaters | Solid-state relay 35 A, 200 to 480 VAC, with built in current transformer, jack-in cage clamp terminals, 2 alarms | |
| ON/OFF control | 1 | DIN rail/screw | Screw | No | Yes | 200-480 V | 180-528 V | 35 A | 100 mm | 55 mm | 130 mm | 9.6-26.4 V | 10 mA | 9.6 V | 1 V | 60 °C | -20 °C | Phototriac | Yes | HB/HS alarm for 3-phase heaters | Solid-state relay 35A, 200 to 480 VAC, with built in current transformer, M3 terminals, 1 alarm | |
| ON/OFF control | 1 | DIN rail/screw | Screw | No | Yes | 200-480 V | 180-528 V | 35 A | 9.6-26.4 V | 10 mA | 9.6 V | 1 V | 60 °C | -20 °C | Phototriac | Yes | HB/HS alarm for 3-phase heaters | Solid-state relay 35A, 200-480VAC, with built in current transformer, jack-in screw terminals, 2 alarms |
